Digital writing pads drawing tablet board NS1560
Key Features
1. Designer drawing on graphic tablet in home office.
Creative design and working concept.
2.Artist creative designer hands sketching of screens for mobile responsive
website development with UI/UX.
3.Developing wireframe sketch layout design mockup on smartphone screen.
Products Specifications
| Display Specification ： | |
| Display type | IPS |
| Screen size | 15.6inch |
| Resolution | 1920*1080 |
| Physical dimension | 449×241×24mm |
| Sensing area | 344.16 mm(L) x 193.59mm(W) |
| Contrast (Typical) | 1000:1 (typ) |
| Brightness | LED light 200cd/㎡ |
| Response time | 10ms |
| Angle of view | 178(89/89) / 178(89/89) (Typ) |
| support color | 16.7M |
| LED life | 15000 hours |
| interface | HDMI |
| Writing Spec ： | |
| touch mode | Battery-free Electromagnetic Resonance |
| Electromagnetic technology | Passive wireless technology |
| Pen resolution | 5080LPI |
| Pen pressure | 8192 levels |
| Report speed | 266PPS |
| Sensing accuracy | ±0.25mm |
| Pen tilt angle | ±45° |
| Induction height | 10mm |
| Digital screen terminal interface | USB、HDML、DC port |
| compatible operating system | Windows 7 or above, Mac OS X 10.10 or above |
